Useful Australian-made cable trays

In Australia, common cable trays include perforated trays, T3 and T5 trays, ladder trays, and cable baskets, made from materials like galvanised steel, aluminium, and stainless steel, all designed to meet AS/NZS electrical standards.

Types of Cable Trays

Perforated Cable Trays are light-duty trays with holes for airflow, helping to prevent overheating of cables. They are suitable for smaller cable loads and fast installation in commercial or light industrial settings. T3 Cable Trays are the industry standard for industrial and commercial applications.

They support higher cable loads than perforated trays and are often used in fire-rated systems due to their heat resistance and structural strength. T5 Cable Trays are heavy-duty trays with deeper sidewalls, allowing maximum cable laying depth. They are ideal for installations requiring high load capacity and durability.

Ladder Trays consist of two side rails connected by rungs, providing strong support for heavy cables and excellent ventilation. They are commonly used in industrial and infrastructure projects. Cable Baskets are open-style trays that offer enhanced ventilation and easy access for maintenance, suitable for power, data, and communication cables.

Materials

Cable trays in Australia are typically made from: Galvanised Steel: Cost-effective, durable, and suitable for most indoor and outdoor applications. Aluminium: Lightweight, corrosion-resistant, and easy to install. Stainless Steel: Highly corrosion-resistant, ideal for harsh environments or outdoor installations.

FR

P (Fibreglass Reinforced Plastic): Used in specialized applications requiring chemical resistance.

Compliance and Standards

Australian cable trays must comply with key standards: AS/NZS 3000 (Wiring Rules): Ensures safe electrical installations. AS/NZS 3013 (Fire Rating of Electrical Equipment): Specifies fire resistance for cable support systems. AS/NZS 1170 (Structural Design Actions): Covers load-bearing requirements.

AS/NZS 2053 (Conduits and Fittings): Ensures compatibility with other electrical components.

Installation Considerations

Ensure adequate spacing to prevent overcrowding and overheating. Use approved fasteners and supports to maintain structural integrity. Select trays based on cable load, environmental conditions, and fire rating.

Regular inspections are recommended to check for corrosion, mechanical wear, or overloading.

Summary

In Australia, the most common cable trays are perforated trays, T3 and T5 trays, ladder trays, and cable baskets, available in galvanised steel, aluminium, stainless steel, or FRP. Proper selection and installation ensure compliance with AS/NZS standards, safe cable management, and long-term durability in commercial, industrial, and residential projects.
