Tips for counting pigtails

The number of pigtails is determined by the type of system: for fiber optics, it depends on the number of fibers to terminate; for electrical boxes, pigtails are not counted in box fill calculations.

Fiber Optic Pigtails

A fiber optic pigtail is a short fiber with a factory-terminated connector on one end and bare fiber on the other, used to splice into a larger fiber cable at an ODF, terminal box, or patch panel. To determine the number of fiber pigtails needed: Count the number of fibers in the main cable that require termination. Each fiber typically requires one pigtail.

Consider spare pigtails for future expansion or replacement. Match the connector type (LC, SC, ST, etc.) to the equipment or patch panel. This ensures proper connectivity and reduces installation time compared to field-terminated connectors.

Electrical Pigtails (Box Fill)In electrical wiring, a pigtail is a short wire connecting multiple conductors to a device or terminal. According to the National Electrical Code (NEC) 314. 16, pigtails do not count toward box fill because they originate and terminate within the box.

To determine box fill: Count each unbroken conductor that passes through or terminates in the box. Count devices, clamps, and fittings according to NEC volume allowances. Ignore short pigtails and wirenuts in the calculation.

Use a box fill calculator or manual calculation to ensure the box volume meets code requirements. This approach ensures compliance with safety standards while avoiding overestimation of box capacity.

Summary

Fiber optic systems: Count one pigtail per fiber to be terminated, plus spares. Electrical systems: Pigtails inside the box are not counted; only through conductors, devices, and fittings are considered for box fill calculations. By following these guidelines, you can accurately determine the number of pigtails needed for both networking and electrical installations.
