Fiber optic cable blowing speed

Fiber and communications infrastructure knowledge brief Published 25 Feb 2023

Use this reference to prepare product questions for BAGYOU FIBRE. Check interfaces, capacity, protection and installation requirements against the current product documentation.

Fiber optic cables can be installed using blowing methods at speeds up to 90 meters per minute, depending on cable type, duct conditions, and equipment used.

Overview of Fiber Optic Cable Blowing

Fiber optic cable blowing, also known as fiber jetting, is a method where high-speed compressed air is combined with a mechanical pushing force to propel the cable through pre-installed ducts. This technique is preferred over traditional pulling because it reduces friction, minimizes labor, and allows faster installation, especially over long distances or ducts with multiple bends.

Typical Installation Speeds

Modern fiber blowing systems can achieve speeds of up to 90 meters per minute (300 feet per minute) for cables ranging from 6mm to 32mm in diameter. The actual speed depends on several factors: Cable stiffness and flexibility: Stiffer cables blow faster through straight ducts, while flexible cables handle complex routes with multiple bends more effectively. Duct size and condition: A slightly larger conduit than the cable diameter reduces friction and allows higher speeds.

Air pressure and pushing force: Compressed air must be optimized; excessive pressure can damage the cable, while insufficient pressure slows installation. Environmental conditions: Temperature affects cable jacket flexibility; cold conditions can make the cable brittle and reduce speed.

Equipment and Best Practices

Blowing machines: Include a cable drive system, air control system, duct clamps, and speed/pressure controls for real-time adjustments. Hydraulic belt systems: Provide smooth control and monitoring of cable feed, ensuring uniform force distribution along the cable length. Preparation: Inspect ducts, verify cable specifications, and ensure proper environmental conditions to maximize speed and prevent damage.

Advantages Over Pulling

Higher efficiency: Blowing allows longer continuous cable runs (over 1000 meters in some cases) with fewer personnel. Reduced friction: The cable “floats” inside the duct due to air flow, minimizing contact with the duct wall. Safety and control: Modern systems include electronic monitoring, emergency stops, and hydraulic control to prevent cable damage.

In summary, fiber optic cable blowing is a fast, efficient, and safe method for laying cables, with installation speeds reaching up to 90 meters per minute, influenced by cable design, duct conditions, and proper use of equipment.
