What are the models of pluggable optical modules

Pluggable optical modules are compact, hot-swappable transceivers that convert electrical signals to optical signals and vice versa, enabling flexible, high-speed fiber optic connectivity in networking and data center environments.

Overview

Pluggable optical modules, also known as small form-factor pluggables (SFPs), are removable modules that allow network devices such as switches, routers, and servers to connect to fiber optic networks. They convert high-speed electrical signals into light pulses for transmission and convert received light back into electrical signals. Introduced in the early 2000s, SFPs replaced larger GBIC modules, enabling higher port density and easier upgrades without replacing the entire device.

Common Types and Form FactorsSFP (Small Form-Factor Pluggable): Standard module for gigabit Ethernet and other high-bandwidth applications. Supports monitoring of voltage, temperature, and optical power in enhanced SFP (eSFP) versions. SFP+: Higher-speed version of SFP, typically for 10 Gbit/s, with improved EMI resistance and tighter module cages.

SFP28: Same interface size as SFP+, supports 25 Gbit/s or backward-compatible 10 Gbit/s modules. QSFP+ / QSFP28: Quad small form-factor pluggable modules supporting 40 Gbit/s and 100 Gbit/s, respectively, often using MPO fiber connectors. QSFP-DD (Double Density): High-speed, four-channel module for 400 Gbit/s, using 8-channel electrical interfaces with NRZ or PAM4 modulation.

XF

P: 10 Gbit/s module with LC fiber connectors, larger than SFP+.

CF

P / CFP2 / CFP4: High-speed modules for data and telecom applications, supporting 100 Gbit/s and beyond.

CX

P: High-density parallel optics transceiver for short multimode links, providing 12 channels in each direction.

CSF

P: Compact SFP with two bidirectional channels for high-density deployments.

OSF

P / OSFP-XD: Octal small form-factor pluggable modules supporting 400 Gbit/s to 1. 6 Tbps, used in high-performance data centers.

XP

O (eXtra-dense Pluggable Optics): Next-generation AI-focused modules delivering up to 12. 8 Tbps per module with liquid-cooled designs, enabling high front-panel density and pay-as-you-grow deployment. Key FeaturesHot-swappable: Modules can be added, removed, or upgraded without powering down the device.

Monitoring: Many modules support real-time monitoring of temperature, voltage, and optical power. Flexibility: Allows network operators to start with lower-cost setups and upgrade individual modules as bandwidth needs increase. High-density support: Enables more ports per device, critical for data centers and high-performance computing environments.

Applications

Pluggable optical modules are widely used in: Data centers: For high-speed interconnects and cloud infrastructure. Enterprise networks: Campus and metropolitan-area networks. Telecommunications: Long-haul and metro fiber networks.

AI and HP

C environments: High-bandwidth, low-latency interconnects for GPUs and AI accelerators.

Recent Developments

Recent innovations focus on higher data rates, increased density, and AI-optimized designs: Kyocera OSFP-XD modules support PCIe 6. 0 interfaces for high-speed CPU/GPU interconnects, enhancing flexibility and power efficiency in data centers.

Arista XP

O modules deliver 12. 8 Tbps per module with liquid cooling, enabling up to 204. 8 Tbps in a single rack unit, addressing AI data center bandwidth demands while maintaining field pluggability.

Pluggable optical modules continue to evolve, balancing speed, density, and operational flexibility, making them essential for modern networking and high-performance computing infrastructures.
